Magewell USB Capture HDMI 4K Plus
3 Years Warranty
Product highlights
- HDMI 2.0/1.4 input and loop-through, audio in/out, USB 3.0 computer interface
- Capture up to 4096 x 2160, 4:4:4, 60 fps
- Compatible with Windows, Mac, Linux, and Chrome OS
- Plug-and-play operation
- UVC protocol support
- Up/down scaling
Déclinaisons
Manfrotto 320PX Plexi Pour Mini Table
|
GARANTIE
|
5 |
| ANS |
320PX
Magewell USB Capture HDMI 4K Plus
|
GARANTIE
|
3 |
| ANS |
32090
|
GARANTIE
|
2 |
| ANS |
320..
Subscribe To When In Stock
You have successfully subscribed to this product
Description
Magewell USB Capture HDMI 4K Plus
In my box
- Magewell USB Capture HDMI 4K Plus
- USB 3.0 Cable
Magewell USB Capture HDMI 4K Plus
The Magewell USB Capture HDMI 4K Plus connects to your computer over a USB interface and lets you capture up to a 4K DCI resolution signal (4096 x 2160) with embedded audio via an HDMI 2.0 input. It allows you to capture from cameras, game consoles, and various other devices directly to your Windows, Mac, Linux, or Chrome computer. It also features an HDMI loop-through for local monitoring, and 3.5mm audio input and output for capturing external audio and extracting embedded audio.
The device also offers a variety of processing and other features, including resolution scaling and deinterlacing. It also has a status LED for displaying the status of the input, including idle, input signal locked, memory failed, or FPGA configuration.
Technical sheet
- Supported Operating Systems : Windows 7/8/8.1/10/2008/2008 R2/2012 (x86 and x64)
- Supported Operating Systems : OS X 10.9 - 10.11
- Supported Operating Systems : macOS 10.12
- Supported Operating Systems : Linux x (Ubuntu 12.04 - 16.10, CentOS 7)
- Supported Operating Systems : Chrome OS
- Input Resolution : Up to 4096 x 2160, 4:4:4, 60 fps input signals
- Supported Sampling Rate : RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
- Input : 1 x HDMI 2.0
- Input : 1 x 3.5 mm audio jack
- Output : 1 x HDMI loop-output
- Output : 1 x 3.5 mm audio jack
- Host Interface : 1 x USB 3.0 (compatible with USB 3.1 Gen 1, USB 2.0)
- Video Capture Formats : Up to 4096 x 2160
- Video Capture Formats : Frame rates up to 120 fps (actual capture frame rate can be limited by USB bandwidth and internal working frequency; typical capture frame rates on the Intel USB 3.0 controller are: 1920 x 1080 YUY2 at up to 90 fps, and 3840 x 2160 NV12 at up to 30 fps)
- Video Capture Formats
- Video Capture Formats : NV12 and I420 4:2:0 8-bit (up to 4096 x 2160)
- Video Capture Formats : YUY2 and UYVY 4:2:2 8-bit (up to 4096 x 2160)
- Video Capture Formats : RGB24 and RGB32 4:4:4 8-bit (up to 2048 x 2160)
- Video Capture Formats : Default capture formats are YUY2 and NV12
- Power Consumption : 5 V Max Current: 1.4 A Max Power Consumption: 7 W
- Operating Temperature : 32 to 104°F
- Storage Temperature : -4 to 158°F
- Relative Humidity : 5 to 90% non-condensing
- Dimensions : 3.9 x 2.2 x 0.7"
Data sheet
32090
€290.40
Tax included
€242.00 No tax
€322.80
Tax included
€269.00
No tax
check
En stock en boutique
Le produit est disponible en ligne ou bien dans notre boutique à Courbevoie (92).
Délai de livraison moyen 2 à 3 jours
Délai de livraison moyen 2 à 3 jours
€290.40
Tax included
€242.00 No tax
€322.80
Tax included
€269.00
No tax
check
En stock en boutique
Le produit est disponible en ligne ou bien dans notre boutique à Courbevoie (92).
Délai de livraison moyen 2 à 3 jours
Délai de livraison moyen 2 à 3 jours
